All-Fluoropolymer Capsule for the Most Aggressive Applications
The Fluorocap? encapsulated filter cartridge is our standard product for aggressive wet etch and clean applications. It provides good flow rates and on-stream life at an economical price. The all-fluoropolymer construction provides excellent chemical resistance for the most aggressive applications up to 180C. Its integral filter design maximizes up-time with safe and simple change-outs. Available wet-packed for quick installation or Ultraclean wet-packed which offers the lowest metals extractables in the industry.
Parker Fluorocap? Cartridge Benefits:
- Economical
- Wide range of conf gurations and ratings
- Wet-pack option for quick installation
- Ultraclean option for absolute cleanliness
- All-fuoropolymer for maximum chemical resistance
- 100% integrity tested for consistent quality
Parker Fluorocap? Cartridge Applications:
- Wet etch and clean
- Hot phosphoric acid
- Sulfuric acid
- Hydrof uoric acid
- Nitric acid
- Piranha SC1,SC2
- NMP-based solvents
- Other high temperature or ozonated processes
Parker Fluorocap? Cartridge Specifications:
Materials of Construction
100% Fluoropolymer construction. All components are thermally bonded to ensure integrity and reduce extractables.
Effective Filtration Area
9.8 ft2 (0.9m2) per 10" f lter length
Metals Extractables*
Standard: <20ppb (total)
Ultraclean: <5ppb (total)
*In a 10% HNO3 extraction
Maximum Differential
Pressure/Temperature
Forward:
80psid (5.5bar) @ 75°F (24°C)
Standard:
55psid (3.8bar) @ 167°F (75°C)
30psid (2.0bar) @ 257°F (125°C)
15psid (1.0bar) @ 300°F (150°C)
Forward HT Option:
100psid (6.8bar) @ 75°F (24°C)
75psid (5.1bar) @ 167°F (75°C)
50psid (3.4bar) @ 257°F (125°C)
15psid (1.0bar) @ 356°F (180°C)
Reverse:
50psid (3.4bar) @ 75°F (24°C)
15psid (1.0bar) @ 250°F (121°C)
Cleanliness (particle shedding)
Wet-packed: <2 particles/ml >0.2m after 7gal @ 1gpm
TOC/Resistivity Rinse-up (wet-packed)
TOC recovery within 3-5ppb of feed after 12gal @ 1gpm.
Resistivity recovery within 0.4megohm-cm of feed after 22gal @ 1gpm.
Download Parker Fluorocap Cartridge Datasheet
Talk to one of our filtration experts today at (855) 737-4717, or fill out our online form to learn more.
All-fluoropolymer capsule for the most aggressive applications
